Description

DMP: diffuser with multiple jet nozzles, individually adjustable

• flow between 20 and 500 m³/h
• application on duct or plenum
• made of combination or steel structure and nylon nozzles
• RAL 9010 finish
• fastening with concealed clips

Accessories

PT: upper entry plenum (on request)

PL: side entry plenum

I: external insulation reaction to fire class B-s2-dO

E: equaliser

FS: fastening with concealed bracket

Special versions

• calendered version
• combined supply and return diffusers (on request)
• nozzles RAL 9005

VR: coating according to RAL 9005 / 9006 table

Other RAL colours on request
