Description

GL: supply and return grilles with fixed bars

• made of natural anodised aluminium
• fastening with snap-on clips
• optional continuous series supply
• maximum length in 1 piece = 2000 mm

GL200: 0° bar inclination, frame 25 mm

GL215: like GL200, 15° bar inclination

GL100: 0° bar inclination, frame 15 mm

GL115: like GL100, 15° bar inclination

GL00: 0° inclination, without frame

GL15: like GL00, 15° inclination

Accessories

SC: control damper for 200 series

CT: counterframe for fastening with snap-on clips

FS: fastening with bracket

PL: plenum with entry side on long side

PT: plenum with rear entry

Special versions

GL200/215: with 20 mm frame

GL...DD: second adjustable row GL...

GL...GD/CD: grille/blank door

W: RAL 9010 coating

VR: coating according to RAL 9005 / 9006 table

Other RAL colours on request
