Product with declaration of Conformity UNI 9494/2 - 2017 for temperatures up to 722 °C

Description

SMVHZ: supply grilles with two rows of adjustable blades (1st vertical)

• made of galvanised steel
• fastening with snap-on clips
• SMHVZ: like SMVHZ but with 1st row of adjustable blades

SMVZ: single row of vertical adjustable blades

SMHZ: single row of horizontal adjustable blades

special terms and conditions: control damper

PL: side entry plenum

PT: plenum with rear entry

I: external anti-condensate insulation reaction to fire class B-s2-dO

CT: counterframe for fastening with snap-on clips

Special versions

SM....W: RAL 9010 finish

SM....X: AISI 304/316 stainless steel finish (on request)

SM....FV: fastening with visible screws (not included)

VR: coating according to RAL 9005 / 9006 table

Other RAL colours on request
